XC7VX1140T-2FLG1930C

ProducentXilinxEURoHSYes with Exemption (2011/65/EU, 2015/863)Automotive No.
Powiadom mnie gdy produkt będzie dostępny
SKU
XC7VX1140T-2FLG1930C_XILINX
0,00 zł

Zapytaj o ten produkt

Opis / XC7VX1140T-2FLG1930C

FPGA Virtex®-7 XT Family 1139200 Cells 28nm Technology 1V 1924-Pin FCBGA Tray

Informacje podstawowe

  • ProducentXilinx
  • EURoHSYes with Exemption (2011/65/EU, 2015/863)
  • Automotive No

Informacje dodatkowe

  • Crosses 1
  • PCNs 19
  • MaskPart XC7VX1140T2FLG1930C%
  • IntroductionDate Jun 21, 2010

Parametry

  • Copy Protection Yes
  • Dedicated DSP 3360
  • Device Logic Cells 1139200
  • Device Logic Gates N/A
  • Device Logic Units 712000
  • Device Number of DLLs/PLLs 24
  • Device System Gates N/A
  • Digital Control Impedance No
  • Ethernet MACs N/A
  • Family Name Virtex®-7 XT
  • Giga Multiply Accumulates per Second N/A
  • I/O Voltage (V) 1.2|1.35|1.5|1.8|2.5|3.3
  • In-System Programmability Yes
  • Maximum Differential I/O Pairs N/A
  • Maximum Distributed RAM Bits 18124800
  • Maximum I/O Performance 28.05Gbps
  • Maximum Internal Frequency (MHz) N/A
  • Maximum Number of SERDES Channels N/A
  • Maximum Number of User I/Os 1100
  • Maximum Operating Supply Voltage (V) 1.03
  • Maximum Operating Temperature (°C) 85
  • Maximum Power Dissipation (mW) N/A
  • Maximum Propagation Delay Time (ns) N/A
  • Maximum Storage Temperature (°C) 150
  • Mega Multiply Accumulates per second N/A
  • Minimum Operating Supply Voltage (V) 0.97
  • Minimum Operating Temperature (°C) 0
  • Minimum Storage Temperature (°C) -65
  • Number of Global Clocks 32
  • Number of I/O Banks 22
  • Number of Inter Dielectric Layers N/A
  • Number of Multipliers 3360 (25x18)
  • Number of Registers 1424000
  • PCI Blocks 4
  • Process Technology 28nm
  • Processor Blocks N/A
  • Program Memory Type SRAM
  • Programmability Yes
  • RAM Bits (Kbit) 67680
  • Reprogrammability Support Yes
  • Shift Registers Utilize LUT
  • Speed Grade 2
  • Supplier Temperature Grade Commercial
  • Temperature Flag Jun
  • Tolerant Configuration Interface Voltage (V) N/A
  • Total Number of Block RAM 1880
  • Tradename Virtex
  • Transceiver Blocks 96
  • Transceiver Speed (Gbps) 28.05
  • Typical Operating Supply Voltage (V) 1
  • Typical Supply Current (mA) N/A

Więcej informacji

Do pobrania Download
Main description FPGA Virtex®-7 XT Family 1139200 Cells 28nm Technology 1V 1924-Pin FCBGA Tray
