XC3S50-4PQ208C
Do pobrania | Download |
---|---|
Main description | FPGA Spartan®-3 Family 50K Gates 1728 Cells 630MHz 90nm Technology 1.2V 208-Pin PQFP |
FPGA Spartan®-3 Family 50K Gates 1728 Cells 630MHz 90nm Technology 1.2V 208-Pin PQFP
Informacje podstawowe
- ProducentXilinx
- EURoHSNo (2011/65/EU, 2015/863)
- Automotive No
Informacje dodatkowe
- Crosses 1271
- Inventory 1
- PCNs 23
- MaskPart XC3S504PQ208C%
- IntroductionDate Jan 05, 1999
Parametry
- Copy Protection No
- Dedicated DSP N/A
- Device Logic Cells 1728
- Device Logic Gates 50000
- Device Logic Units 1728
- Device Number of DLLs/PLLs 2
- Device System Gates 50000
- Digital Control Impedance Yes
- Ethernet MACs N/A
- Family Name Spartan®-3
- Giga Multiply Accumulates per Second N/A
- I/O Voltage (V) 1.2|1.5|1.8|2.5|3.3
- In-System Programmability Yes
- Maximum Differential I/O Pairs 56
- Maximum Distributed RAM Bits 12288
- Maximum I/O Performance 622Mbps
- Maximum Internal Frequency (MHz) 630
- Maximum Number of SERDES Channels N/A
- Maximum Number of User I/Os 124
- Maximum Power Dissipation (mW) N/A
- Maximum Propagation Delay Time (ns) N/A
- Mega Multiply Accumulates per second N/A
- Number of Global Clocks 8
- Number of I/O Banks 8
- Number of Inter Dielectric Layers 8
- Number of Multipliers 4 (18x18)
- Number of Registers N/A
- PCI Blocks N/A
- Process Technology 90nm
- Processor Blocks N/A
- Program Memory Type SRAM
- Programmability No
- RAM Bits (Kbit) 72
- Reprogrammability Support Yes
- Shift Registers Utilize LUT
- Speed Grade 4
- Supplier Temperature Grade Commercial
- Temperature Flag Jun
- Tolerant Configuration Interface Voltage (V) 3.3
- Total Number of Block RAM 4
- Tradename Spartan
- Transceiver Blocks N/A
- Transceiver Speed (Gbps) N/A
- Typical Supply Current (mA) N/A
