NCP5230MNTWG

ProducentON SemiconductorEURoHSYes (2011/65/EU, 2015/863)Automotive No.
Powiadom mnie gdy produkt będzie dostępny
SKU
NCP5230MNTWG_ON_SEMICONDUCTOR
0,00 zł

Zapytaj o ten produkt

Opis / NCP5230MNTWG

DC/DC Cntrlr Single-OUT Step Down 1000kHz 16-Pin QFN EP T/R

Informacje podstawowe

  • ProducentON Semiconductor
  • EURoHSYes (2011/65/EU, 2015/863)
  • Automotive No

Informacje dodatkowe

  • Crosses 182
  • Inventory 7
  • PCNs 19
  • GIDEP-Alerts 1
  • MaskPart NCP5230MNTWG%
  • SupplierUrl http://www.onsemi.com/PowerSolutions/search.do?query=NCP5230MNTWG&tabbed=Y&clearFilters=Y&searchType=others

Parametry

  • Maximum Input Voltage (V) 19
  • Maximum Operating Temperature (°C) 85
  • Maximum Power Dissipation (mW) N/A
  • Maximum Storage Temperature (°C) 150
  • Maximum Supply Current (mA) 5
  • Maximum Switching Frequency (kHz) 1000
  • Minimum Input Voltage (V) 1.5
  • Minimum Operating Temperature (°C) 0
  • Minimum Storage Temperature (°C) -55
  • Minimum Switching Frequency (kHz) 100
  • Number of Outputs 1
  • Operating Supply Voltage (V) 4.5 to 13.2
  • Output Voltage (V) 0.8 to 3.3|5
  • Supplier Temperature Grade N/A
  • Topology Step Down
  • Typical Gate Driver Pull Down Resistance (Ohm) 1/2
  • Typical Gate Driver Pull Up Resistance (Ohm) 2/2.5
  • Typical Input Voltage (V) N/A
  • Typical Output Current (A) N/A
  • Typical Quiescent Current (mA) N/A

Więcej informacji

Do pobrania Download
Main description DC/DC Cntrlr Single-OUT Step Down 1000kHz 16-Pin QFN EP T/R
