NCP1835MN20R2G

ProducentON SemiconductorEURoHSYes (2011/65/EU, 2015/863)Automotive No.
Powiadom mnie gdy produkt będzie dostępny
SKU
NCP1835MN20R2G_ON_SEMICONDUCTOR
0,00 zł

Zapytaj o ten produkt

Opis / NCP1835MN20R2G

Linear Battery Charger Li-Ion 1000mA 4.2V 10-Pin DFN EP T/R

Informacje podstawowe

  • ProducentON Semiconductor
  • EURoHSYes (2011/65/EU, 2015/863)
  • Automotive No

Informacje dodatkowe

  • Crosses 326
  • PCNs 22
  • MaskPart NCP1835MN20%G
  • IntroductionDate Apr 01, 2005
  • SupplierUrl http://www.onsemi.com/PowerSolutions/search.do?query=NCP1835MN20R2G&tabbed=Y&clearFilters=Y&searchType=others

Parametry

  • Battery Type Li-Ion
  • Maximum Operating Supply Voltage (V) 6.5
  • Maximum Operating Temperature (°C) 70
  • Maximum Power Dissipation (mW) 1090
  • Maximum Supply Current (mA) N/A
  • Minimum Operating Supply Voltage (V) 2.8
  • Minimum Operating Temperature (°C) -20
  • Operating Supply Voltage (V) N/A
  • Output Current (mA) 1000
  • Output Voltage (V) 4.2
  • Supplier Temperature Grade N/A
  • Type Linear Battery Charger
  • Typical Operating Supply Voltage (V) N/A

Więcej informacji

Do pobrania Download
Main description Linear Battery Charger Li-Ion 1000mA 4.2V 10-Pin DFN EP T/R
