MIC28304-2YMP

ProducentMicrochip TechnologyEURoHSYes (2002/95/EC)Automotive No.
Powiadom mnie gdy produkt będzie dostępny
SKU
MIC28304-2YMP_MICROCHIP_TECHNOLOGY
0,00 zł

Zapytaj o ten produkt

Opis / MIC28304-2YMP

1-OUT 0.9V to 24V 3A

Informacje podstawowe

  • ProducentMicrochip Technology
  • EURoHSYes (2002/95/EC)
  • Automotive No

Informacje dodatkowe

  • Crosses 1
  • Inventory 4*
  • PCNs 45
  • MaskPart MIC283042YMP%
  • IntroductionDate Feb 15, 2014

Parametry

  • Efficiency (%) N/A
  • Isolation N/A
  • Line Regulation 0.36%(Typ)
  • Load Regulation 0.05%(Typ)
  • Maximum Input Voltage (V) 70
  • Maximum Operating Temperature (°C) 125
  • Maximum Output Current (A) 3
  • Maximum Output Power (W) N/A
  • Maximum Storage Temperature (°C) 150
  • Minimum Input Voltage (V) 4.5
  • Minimum Isolation Voltage N/A
  • Minimum Operating Temperature (°C) -40
  • Minimum Storage Temperature (°C) -65
  • Number of Outputs 1
  • On/Off Logic Positive
  • Output Type Adjustable
  • Output Voltage (V) 0.9 to 24
  • Process Technology N/A
  • Supplier Temperature Grade N/A
  • Switching Frequency (kHz) 200 to 600
  • Switching Regulator Yes
  • Tradename HyperLight Load™
  • Type Step Down
  • Typical Input Voltage (V) N/A
  • Typical Standby Current (mA) N/A

Więcej informacji

Do pobrania Download
Main description 1-OUT 0.9V to 24V 3A
