MCP3553T-E/SN

ProducentMicrochip TechnologyEURoHSYes (2011/65/EU, 2015/863)Automotive Yes.
Powiadom mnie gdy produkt będzie dostępny
SKU
MCP3553T-E_SN_MICROCHIP_TECHNOLOGY
0,00 zł

Zapytaj o ten produkt

Opis / MCP3553T-E/SN

1-Channel Single ADC Delta-Sigma 60sps 20.6-bit Serial Automotive 8-Pin SOIC N T/R

Informacje podstawowe

  • ProducentMicrochip Technology
  • EURoHSYes (2011/65/EU, 2015/863)
  • Automotive Yes

Informacje dodatkowe

  • Crosses 131
  • Inventory 1
  • PCNs 59
  • GIDEP-Alerts 11
  • MaskPart MCP3553%ESN
  • IntroductionDate Sep 26, 2005

Parametry

  • Architecture Delta-Sigma
  • Converter Type Temperature Measurement
  • Differential Input Yes
  • Differential Nonlinearity N/A
  • Digital Interface Type Serial (2-Wire, 3-Wire, SPI)
  • Digital Supply Support No
  • Full Scale Error ±10ppm
  • Input Signal Type Differential
  • Input Type Voltage
  • Input Voltage ±2.5V
  • Integral Nonlinearity Error 6ppm
  • Maximum Dual Supply Voltage (V) N/R
  • Maximum Operating Temperature (°C) 85
  • Maximum Power Dissipation (mW) N/A
  • Maximum Single Supply Voltage (V) 5.5
  • Minimum Dual Supply Voltage (V) N/R
  • Minimum Operating Temperature (°C) -40
  • Minimum Single Supply Voltage (V) 2.7
  • No Missing Codes (bit) 20
  • Number of ADCs 1
  • Number of Input Channels 1
  • Polarity of Input Voltage Bipolar
  • Resolution 20.6bit
  • Sample and Hold No
  • Sampling Rate 60sps
  • Signal to Noise Ratio N/A
  • Single-Ended Input No
  • Supplier Temperature Grade N/A
  • Typical Dual Supply Voltage (V) N/R
  • Typical Power Dissipation (mW) N/A
  • Typical Single Supply Voltage (V) 5
  • Voltage Reference External
  • Voltage Supply Source Single

Więcej informacji

Do pobrania Download
Main description 1-Channel Single ADC Delta-Sigma 60sps 20.6-bit Serial Automotive 8-Pin SOIC N T/R
