MCP1804T-A002I/MB

ProducentMicrochip TechnologyEURoHSYes (2011/65/EU, 2015/863)Automotive No.
Powiadom mnie gdy produkt będzie dostępny
SKU
MCP1804T-A002I_MB_MICROCHIP_TECHNOLOGY
0,00 zł

Zapytaj o ten produkt

Opis / MCP1804T-A002I/MB

LDO Regulator Pos 10V 0.15A 4-Pin(3+Tab) SOT-89 T/R

Informacje podstawowe

  • ProducentMicrochip Technology
  • EURoHSYes (2011/65/EU, 2015/863)
  • Automotive No

Informacje dodatkowe

  • Crosses 60
  • Inventory 1
  • PCNs 48
  • GIDEP-Alerts 1
  • MaskPart MCP1804TA002IMB%
  • IntroductionDate Sep 03, 2009

Parametry

  • Accuracy (%) ±2
  • Junction to Ambient 180°C/W(Typ)
  • Junction to Case 100°C/W(Typ)
  • Line Regulation 0.3%/V
  • Load Regulation 175mV
  • Maximum Dropout Voltage @ Current (V) 0.19@20mA|0.95@100mA
  • Maximum Input Voltage (V) 28
  • Maximum Operating Temperature (°C) 85
  • Maximum Output Current (A) 0.15(Min)
  • Maximum Power Dissipation (mW) N/A
  • Maximum Quiescent Current (mA) 0.115
  • Maximum Storage Temperature (°C) 125
  • Minimum Input Voltage (V) 2
  • Minimum Operating Temperature (°C) -40
  • Minimum Storage Temperature (°C) -55
  • Noise Spectral Density (uV/rtHz) N/A
  • Number of Outputs 1
  • Output Capacitor Type Ceramic|Tantalum
  • Output Type Fixed
  • Output Voltage (V) 10
  • Output Voltage Range (V) 10 to 20
  • Pass Element Type PMOS
  • Polarity Positive
  • Reference Voltage (V) N/A
  • Special Features Current Limit|Short Circuit Protection|Shutdown
  • Supplier Temperature Grade Industrial
  • Type LDO
  • Typical Bias Voltage (VDC) N/A
  • Typical Dropout Voltage @ Current (V) 0.13@20mA|0.7@100mA
  • Typical Ground Current @ Full Load (mA) N/A
  • Typical Output Capacitance (uF) 0.1
  • Typical Output Noise Voltage (uVrms) N/A
  • Typical PSRR (dB) 50
  • Typical Power Dissipation (mW) N/A
  • Typical Quiescent Current (mA) 0.06

Więcej informacji

Do pobrania Download
Main description LDO Regulator Pos 10V 0.15A 4-Pin(3+Tab) SOT-89 T/R
