MCP1754ST-3002E/MB

ProducentMicrochip TechnologyEURoHSYes (2011/65/EU, 2015/863)Automotive Yes.
Powiadom mnie gdy produkt będzie dostępny
SKU
MCP1754ST-3002E_MB_MICROCHIP_TECHNOLOGY
0,00 zł

Zapytaj o ten produkt

Opis / MCP1754ST-3002E/MB

LDO Regulator Pos 3V 0.15A Automotive 4-Pin(3+Tab) SOT-89 T/R

Informacje podstawowe

  • ProducentMicrochip Technology
  • EURoHSYes (2011/65/EU, 2015/863)
  • Automotive Yes

Informacje dodatkowe

  • Crosses 269
  • PCNs 45
  • MaskPart MCP1754ST3002EMB%

Parametry

  • Accuracy (%) ±2
  • Junction to Ambient 153.3°C/W(Typ)
  • Junction to Case 100°C/W(Typ)
  • Line Regulation 0.01%/V(Typ)
  • Load Regulation -0.4%(Typ)
  • Maximum Dropout Voltage @ Current (V) 0.5@150mA
  • Maximum Input Voltage (V) 16
  • Maximum Operating Temperature (°C) 150
  • Maximum Output Current (A) 0.15(Min)
  • Maximum Power Dissipation (mW) N/A
  • Maximum Quiescent Current (mA) 0.09
  • Maximum Storage Temperature (°C) 150
  • Minimum Input Voltage (V) 3.6
  • Minimum Operating Temperature (°C) -40
  • Minimum Storage Temperature (°C) -55
  • Noise Spectral Density (uV/rtHz) 3@1kHz
  • Number of Outputs 1
  • Output Capacitor Type Ceramic|Tantalum
  • Output Type Fixed
  • Output Voltage (V) 3
  • Output Voltage Range (V) 1.8 to 10
  • Pass Element Type PMOS
  • Polarity Positive
  • Reference Voltage (V) N/A
  • Special Features Current Limit|Good Power Signal|Short Circuit Protection
  • Supplier Temperature Grade N/A
  • Type LDO
  • Typical Bias Voltage (VDC) N/A
  • Typical Dropout Voltage @ Current (V) 0.3@150mA
  • Typical Ground Current @ Full Load (mA) 0.15
  • Typical Output Capacitance (uF) 1
  • Typical Output Noise Voltage (uVrms) N/A
  • Typical PSRR (dB) 72
  • Typical Power Dissipation (mW) N/A
  • Typical Quiescent Current (mA) 0.056

Więcej informacji

Do pobrania Download
Main description LDO Regulator Pos 3V 0.15A Automotive 4-Pin(3+Tab) SOT-89 T/R
