MAX9860ETG+T

ProducentMaxim IntegratedEURoHSYes (2011/65/EU, 2015/863)Automotive No.
Powiadom mnie gdy produkt będzie dostępny
SKU
MAX9860ETG+T_MAXIM_INTEGRATED
0,00 zł

Zapytaj o ten produkt

Opis / MAX9860ETG+T

Voiceband Audio Codec 1ADC / 2DAC Ch 24-Pin TQFN EP T/R

Informacje podstawowe

  • ProducentMaxim Integrated
  • EURoHSYes (2011/65/EU, 2015/863)
  • Automotive No

Informacje dodatkowe

  • Crosses 1
  • Inventory 3
  • PCNs 9
  • GIDEP-Alerts 1
  • MaskPart MAX9860ETG+%
  • IntroductionDate Oct 01, 2008

Parametry

  • ADC/DAC Resolution (bit) 16
  • Interface Type Serial (2-Wire, I2C, I2S)
  • Maximum Operating Supply Voltage (V) 1.9|3.6
  • Maximum Operating Temperature (°C) 85
  • Maximum Power Dissipation (mW) 2222
  • Minimum Operating Supply Voltage (V) 1.7
  • Minimum Operating Temperature (°C) -40
  • Number of ADC Inputs 2
  • Number of ADCs 1
  • Number of Channels 1ADC / 2DAC
  • Number of DAC Outputs 1
  • Number of DACs 2
  • Operating Supply Voltage (V) 1.8
  • Power Supply Type Analog|Digital
  • Sampling Rate (ksps) 48
  • Signal to Noise Ratio (dB) N/A
  • Supplier Temperature Grade Extended
  • Total Harmonic Distortion Plus Noise (THD+N) (dB) -87
  • Type Voiceband
  • Typical Operating Supply Voltage (V) 1.8

Więcej informacji

Do pobrania Download
Main description Voiceband Audio Codec 1ADC / 2DAC Ch 24-Pin TQFN EP T/R
