LT1940EFE#PBF

ProducentAnalog DevicesEURoHSYes (2011/65/EU, 2015/863)Automotive No.
Powiadom mnie gdy produkt będzie dostępny
SKU
LT1940EFE#PBF_ANALOG_DEVICES
0,00 zł

Zapytaj o ten produkt

Opis / LT1940EFE#PBF

Conv DC-DC 3.6V to 25V Step Down Dual-Out 1.25V to 22V 1.4A 16-Pin TSSOP EP Tube

Informacje podstawowe

  • ProducentAnalog Devices
  • EURoHSYes (2011/65/EU, 2015/863)
  • Automotive No

Informacje dodatkowe

  • Crosses 14
  • Inventory 4
  • PCNs 10
  • MaskPart LT1940EFE#PBF%
  • IntroductionDate Aug 06, 2002

Parametry

  • Efficiency (%) N/A
  • Isolation N/A
  • Line Regulation 0.005%/V(Typ)
  • Load Regulation N/A
  • Maximum Input Voltage (V) 25
  • Maximum Operating Temperature (°C) 85
  • Maximum Output Current (A) 1.4
  • Maximum Output Power (W) N/A
  • Minimum Input Voltage (V) 3.6
  • Minimum Isolation Voltage N/A
  • Minimum Operating Temperature (°C) -40
  • Number of Outputs 2
  • Operating Supply Voltage (V) 3.6 to 25
  • Output Type Adjustable
  • Output Voltage (V) 1.25 to 22
  • Supplier Temperature Grade Extended
  • Switching Frequency (kHz) 1250
  • Switching Regulator Yes
  • Technology N/A
  • Type Step Down
  • Typical Input Voltage (V) N/A
  • Typical Quiescent Current (uA) 3800

Więcej informacji

Do pobrania Download
Main description Conv DC-DC 3.6V to 25V Step Down Dual-Out 1.25V to 22V 1.4A 16-Pin TSSOP EP Tube
