L6569AD013TR
| Do pobrania | Download |
|---|---|
| Main description | Driver 600V 0.275A 2-OUT High and Low Side Half Brdg Inv/Non-Inv 8-Pin SO N T/R |
Driver 600V 0.275A 2-OUT High and Low Side Half Brdg Inv/Non-Inv 8-Pin SO N T/R
Informacje podstawowe
- ProducentSTMicroelectronics
- EURoHSYes (2011/65/EU, 2015/863)
- Automotive No
Informacje dodatkowe
- Crosses 108
- Inventory 2
- PCNs 18
- MaskPart L6569AD%
- IntroductionDate Jun 19, 2000
Parametry
- Absolute Propagation Delay Time (ns) N/A
- Bridge Type Half Bridge
- Driver Configuration Inverting|Non-Inverting
- Driver Type High and Low Side
- High and Low Sides Dependency Synchronous
- Input Logic Compatibility N/A
- Maximum Fall Time (ns) N/A
- Maximum Power Dissipation (mW) N/A
- Maximum Propagation Delay Time (ns) N/A
- Maximum Rise Time (ns) N/A
- Maximum Supply Current (mA) 25
- Maximum Turn-Off Delay Time (ns) N/A
- Maximum Turn-On Delay Time (ns) N/A
- Number of Drivers 2
- Number of Outputs 2
- Output Resistance (Ohm) N/A
- Peak Output Current (A) 0.275(Typ)
- Reference Voltage (V) 600(Max)
- Special Features Under Voltage Lockout
- Supplier Temperature Grade N/A
- Type IGBT
- Typical Input High Threshold Voltage (V) N/A
- Typical Input Low Threshold Voltage (V) N/A
