DM-04-V

Więcej informacji
Do pobrania Download
Main description Switch DIP OFF ON SPST 4 Raised Slide 0.025A 24VDC Gull Wing 2000Cycles 2.54mm SMD Tube
Switch DIP OFF ON SPST 4 Raised Slide 0.025A 24VDC Gull Wing 2000Cycles 2.54mm SMD Tube

Informacje podstawowe

  • ProducentDiptronics manufacturing
  • EURoHSYes (2011/65/EU, 2015/863)
  • Automotive No

Informacje dodatkowe

  • Crosses 47
  • Inventory 1
  • MaskPart DM04V%
  • IntroductionDate Oct 01, 2004

Parametry

  • Actuator Material Nylon Thermoplastic
  • Coding N/A
  • Contact Material Copper Alloy
  • Contact Plating Gold/Nickel
  • Dielectric Strength 500VAC
  • Electrical Life (Cycles) 2000
  • Maximum AC Voltage Rating (V) N/A
  • Maximum Contact Resistance (mOhm) 50
  • Maximum Current Rating (A) 0.025@24VDC
  • Maximum DC Voltage Rating (V) 24
  • Maximum Nonswitching Current (mA) 100
  • Maximum Operating Temperature (°C) 85
  • Maximum Power Rating (VA) N/A
  • Maximum Storage Temperature (°C) 85
  • Mechanical Life (Cycles) 2000
  • Minimum Insulation Resistance (MOhm) 100
  • Minimum Operating Temperature (°C) -20
  • Minimum Storage Temperature (°C) -40
  • Number of Positions 4
  • Operating Temperature (°C) -20 to 85
  • Pole Throw Configuration SPST
  • Seal No
  • Seal Description N/R
  • Seal Location N/R
  • Switch Configuration OFF ON
  • Type DIP Switch
