CY7C65213-28PVXI

ProducentCypress SemiconductorEURoHSYes (2011/65/EU, 2015/863)Automotive No.
Powiadom mnie gdy produkt będzie dostępny
SKU
CY7C65213-28PVXI_CYPRESS_SEMICONDUCTOR
0,00 zł

Zapytaj o ten produkt

Opis / CY7C65213-28PVXI

Full Speed USB Controller USB 2.0 3.3V/5V Tube 28-Pin SSOP

Informacje podstawowe

  • ProducentCypress Semiconductor
  • EURoHSYes (2011/65/EU, 2015/863)
  • Automotive No

Informacje dodatkowe

  • Crosses 1
  • Inventory 7
  • PCNs 32
  • GIDEP-Alerts 2
  • MaskPart CY7C6521328PVXI%
  • IntroductionDate Jan 01, 2000
  • SupplierUrl http://www.cypress.com/?app=search&searchType=part&keywords=CY7C65213-28PVXI

Parametry

  • Interface Type UART
  • Maximum Data Rate (Mbps) 3
  • Maximum Operating Frequency (MHz) 48
  • Maximum Operating Supply Voltage (V) 3.45|5.25
  • Maximum Operating Temperature (°C) 85
  • Maximum Storage Temperature (°C) 100
  • Minimum Operating Supply Voltage (V) 3.15|4.35
  • Minimum Operating Temperature (°C) -40
  • Minimum Storage Temperature (°C) -55
  • Protocols Supported USB 2.0
  • Supplier Temperature Grade Industrial
  • Type USB Controller
  • Typical Operating Supply Voltage (V) 3.3|5
  • Typical Supply Current (mA) 13
  • USB Speed Type Full Speed
  • USB Transceiver Yes

Więcej informacji

Do pobrania Download
Main description Full Speed USB Controller USB 2.0 3.3V/5V Tube 28-Pin SSOP
