ATmega16U2-MUR
| Do pobrania | Download |
|---|---|
| Main description | MCU 8-bit AVR RISC 16KB Flash 3.3V/5V 32-Pin QFN EP T/R |
MCU 8-bit AVR RISC 16KB Flash 3.3V/5V 32-Pin QFN EP T/R
Informacje podstawowe
- ProducentMicrochip Technology
- EURoHSYes (2011/65/EU, 2015/863)
- Automotive No
Informacje dodatkowe
- Crosses 9
- Inventory 6
- PCNs 52
- GIDEP-Alerts 4
- MaskPart ATMEGA16U2MUR%
- IntroductionDate Jul 07, 2009
Parametry
- ADC Channels N/A
- ADC Resolution (bit) N/A
- Analog Comparators 1
- CAN 0
- Core Architecture AVR
- DAC Channels N/A
- DAC Resolution (bit) N/A
- DMA Channels N/A
- Data Bus Width (bit) 8
- Data Memory Size N/A
- Device Core AVR
- Display Driver N/A
- Ethernet 0
- Family Name ATmega
- I2C 0
- I2S 0
- Instruction Set Architecture RISC
- Interface Type SPI/USART/USB
- LCD Segments N/A
- Maximum CPU Frequency (MHz) 16
- Maximum Clock Rate (MHz) 16
- Maximum Expanded Memory Size N/A
- Maximum Power Dissipation (mW) N/A
- Maximum Storage Temperature (°C) 150
- Minimum Storage Temperature (°C) -65
- Number of ADCs N/A
- Number of DACs N/A
- Number of Programmable I/Os 22
- Number of Timers 3
- PWM 5
- Program Memory Size 16KB
- Program Memory Type Flash
- Programmability Yes
- RAM Size 512B
- SPI 2
- Special Features N/A
- Supplier Temperature Grade Industrial
- Temperature Flag Opr
- UART 1
- USART 1
- USB 1
- Watchdog 1
