AD9852ASVZ
Do pobrania | Download |
---|---|
Main description | Direct Digital Synthesizer 300MHz 2-DAC 12bit Parallel/Serial 80-Pin TQFP EP Tray |
Direct Digital Synthesizer 300MHz 2-DAC 12bit Parallel/Serial 80-Pin TQFP EP Tray
Informacje podstawowe
- ProducentAnalog Devices
- EURoHSYes (2011/65/EU, 2015/863)
- Automotive No
Informacje dodatkowe
- Inventory 8
- PCNs 13
- MaskPart AD9852ASVZ%
- IntroductionDate May 11, 2007
Parametry
- Digital Interface Type Parallel|Serial (2-Wire, 3-Wire, SPI)
- Digital Supply Support No
- Internal Frequency Multiplier Yes
- Maximum Input Frequency (MHz) 300
- Maximum Power Dissipation (mW) 3200
- Maximum Storage Temperature (°C) 150
- Maximum Supply Current (mA) 992
- Minimum Storage Temperature (°C) -65
- Number of DACs 2
- Number of Outputs 2
- Output Type Current
- Resolution (bit) 12
- Signal to Noise Ratio (dB) N/A
- Supplier Temperature Grade Extended Industrial
- Tuning Word Width (bit) 48
- Typical Output Current (mA) 10
- Typical Output Voltage (V) N/A
