AD9410BSVZ

ProducentAnalog DevicesEURoHSYes (2011/65/EU, 2015/863)Automotive No.
Powiadom mnie gdy produkt będzie dostępny
SKU
AD9410BSVZ_ANALOG_DEVICES
0,00 zł

Zapytaj o ten produkt

Opis / AD9410BSVZ

1-Channel Single ADC Pipelined 210Msps 10-bit Parallel 80-Pin TQFP EP Tray

Informacje podstawowe

  • ProducentAnalog Devices
  • EURoHSYes (2011/65/EU, 2015/863)
  • Automotive No

Informacje dodatkowe

  • Inventory 4
  • PCNs 14
  • MaskPart AD9410BSVZ%
  • IntroductionDate Oct 01, 2000

Parametry

  • Architecture Pipelined
  • Converter Type General Purpose
  • Differential Input Yes
  • Differential Nonlinearity -1/1.5LSB
  • Digital Interface Type Parallel
  • Digital Supply Support No
  • Full Scale Error ±6%FSR
  • Input Signal Type Differential
  • Input Type Voltage
  • Input Voltage ±0.768Vp-p
  • Integral Nonlinearity Error ±3LSB
  • Maximum Dual Supply Voltage (V) N/R
  • Maximum Operating Temperature (°C) 85
  • Maximum Power Dissipation (mW) 2400
  • Maximum Single Supply Voltage (V) 3.465/5.25
  • Maximum Storage Temperature (°C) 150
  • Minimum Dual Supply Voltage (V) N/R
  • Minimum Operating Temperature (°C) -40
  • Minimum Single Supply Voltage (V) 3.135/4.75
  • Minimum Storage Temperature (°C) -65
  • No Missing Codes (bit) N/A
  • Number of ADCs 1
  • Number of Input Channels 1
  • Polarity of Input Voltage Unipolar
  • Resolution 10bit
  • Sample and Hold Yes
  • Sampling Rate 210Msps
  • Signal to Noise Ratio 55dB(Typ)
  • Single-Ended Input No
  • Supplier Temperature Grade Industrial
  • Typical Dual Supply Voltage (V) N/R
  • Typical Power Dissipation (mW) 2000
  • Typical Single Supply Voltage (V) 3.3/5
  • Voltage Reference Internal|External
  • Voltage Supply Source Single

Więcej informacji

Do pobrania Download
Main description 1-Channel Single ADC Pipelined 210Msps 10-bit Parallel 80-Pin TQFP EP Tray
