24LC16B-E/P
Do pobrania | Download |
---|---|
Main description | EEPROM Serial-I2C 16K-bit 8Block x 256 x 8 3.3V/5V Automotive 8-Pin PDIP Tube |
EEPROM Serial-I2C 16K-bit 8Block x 256 x 8 3.3V/5V Automotive 8-Pin PDIP Tube
Informacje podstawowe
- ProducentMicrochip Technology
- EURoHSYes (2011/65/EU, 2015/863)
- Automotive Yes
Informacje dodatkowe
- Crosses 370
- Inventory 5
- PCNs 84
- GIDEP-Alerts 6
- MaskPart 24LC16B%EP
- IntroductionDate Sep 19, 1996
Parametry
- Data Retention (Year) 200(Min)
- Density (bit) 16K
- Density in Bits (bit) 16384
- Hardware Data Protection Yes
- Interface Type Serial-I2C
- Maximum Access Time (ns) 900
- Maximum Storage Temperature (°C) 150
- Minimum Storage Temperature (°C) -65
- Organization 8Blockx256x8
- Output Enable Access Time (ns) N/A
- Programmability Yes
- Programming Voltage (V) 2.5 to 5.5
- Supplier Temperature Grade Automotive
